Pipe belt conveyor
Product description
Pipe belt conveyor is a new type belt conveyor developed on the basis of trough belt conveyor. We can enlarge the wrap angle of belt to realize conveying material in sealed space. Besides the advantages of general belt conveyor of big conveying capacity, simple structure, convenient using function and strong adaptability etc., which also has the following advantages:
1、conveying material in sealed space
2、can be arranged along space curve
3、can realize big dip conveying
4middle conveying part with small width
5、can use the upper and lower branch to convey different material
6、can conveying all kinds of material, and widely used in iron and steel, mining, coal, power plant, cement plant, chemical industry and paper making etc. industries.
We company independently exploit new generation SDGD type pipe belt conveyor which has our own intellectual property, and it has been successfully used at coal conveying system of Taigang, Huaigang and partial power plant etc. 10 projects.
Specifications of tubular belt conveyor
|
|
|
|
|
|
|
| model |
|
|
|
|
|
|
|
(mm) |
(mm) |
(mm) |
m2 |
(mm) |
|
JKGD01 |
φ100 |
100.2 |
430 |
0.0059 |
20~30 |
|
JKGD02 |
φ150 |
150.7 |
600 |
0.0134 |
30~50 |
|
JKGD03 |
φ200 |
199.1 |
780(800) |
0.0234 |
50~70 |
|
JKGD04 |
φ250 |
263.5 |
1000 |
0.0409 |
70~90 |
|
JKGD05 |
φ300 |
285.2 |
1100(1200) |
0.0479 |
90~100 |
|
JKGD06 |
φ350 |
334.3 |
1300(1400) |
0.0658 |
100~120 |
|
JKGD07 |
φ400 |
426.5 |
1600 |
0.1071 |
120~150 |
|
JKGD08 |
φ500 |
509.5 |
1900(2000) |
0.1529 |
150~200 |
|
JKGD09 |
φ600 |
603.5 |
2250 |
0.2145 |
200~250 |
|
JKGD10 |
φ700 |
690.6 |
2550 |
0.2809 |
250~300 |
|
JKGD11 |
φ850 |
828.1 |
3100 |
0.4041 |
300~400 |
Note: The cross-sectional area is the area with a loading rate of 75%
